22 TON PEE-WEE "P20.8G CNC AC" FULLY-AUTOMATED COLD-FORMING THREAD ROLLER w/SIEMENS CNC CONTROL - LOADING ROBOT - BOWL-TYPE VIBRATORY FEEDER - 0.157" TO 1.97" WORK DIAMETER RANGE
Have one to sell?
$69,500.00 USD
ConditionUsed
1 available
22 TON PEE-WEE "P20.8G CNC AC"
FULLY-AUTOMATED COLD-FORMING THREAD ROLLER
New 2012, Installed 2014, Serial No P11.0122,
Model P20.8G CNC-AC
Siemens "Simatic" Mobile Panel CNC Controller
HJ3 Automation/Shunk Overhead Automated Loading Robot
(Model 618180, Serial No 60807) w/Bowl-Type Vibratory
Feeder
AC Servo-Drives
7.5 KW Hydac Hydraulic Unit
Forming Force, Range 10 to 200 Kn
Forming Force, Range 1 to 22.4 TONS
Tool Diameter, Range 130 to 200 MM
Tool Diameter, Range 5.12" to 7.87"
Shaft Diameter 54/69.85 MM
Shaft Diameter 2.12/2.75"
Support Length 180 MM
Support Length 7"
Work Piece Diameter, Range 4 to 50 MM
Work Piece Diameter, Range .157" to 1.97"
Hydraulic Unit 7.5 KW 10 HP
Weight Approximately 2300 KG 5060 LBS
F.O.B. OUR WAREHOUSE
